Question:
How can I deactivate displaying symbols for the FE mesh refinement?
Answer:
You can find the setting for this in the Display navigator, under "Model", and "FE Mesh Refinements".
If you unselect the checkbox, the symbol for the FE mesh refinement will no longer be displayed in the structure.
