Question:
Where can I set which elements are to be displayed in a graphic?
Answer:
You can make this setting using Project Navigator - Display.
The Display navigator is activated with the second tab at the bottom of the navigator. The objects in the graphic can be displayed or hidden in a clearly arranged tree structure. To do this, you only have to activate or deactivate the check boxes in front of the entries.
