[EN] FAQ 004540 | In Project Navigator - Display, I have set the "With Diagram" option for ...

Question:
In Project Navigator - Display, I have set the "With Diagram" option for displaying the results of members. However, the results are displayed without the diagram. Why?

Answer:
The results are displayed without a diagram if a display factor for the member distributions equal to zero is defined in the panel (Image 01).

If you define a display factor for the member diagrams greater than zero in the panel, the member diagrams are also displayed (Image 02).
