In this webinar we show you how to use the structural analysis software RFEM for modeling beam and surface structures made of timber, entering loads, and combining load cases.
Time Schedule:
00:00 Introduction
01:50 Modeling beam and surface elements in RFEM
38:45 Entering loads manually and using load generators
1:01:00 Creating load and result combinations automatically
