Question:
I encountered a sharing violation while importing a dxf file into SHAPE-THIN. What is the issue?
Answer:
The dxf file is currently being used by another program such as CAD. Close the file and import the file again.
FAQ 005036 | I encountered a sharing violation while importing a dxf file into SHAPE-THIN. What i...
