This video will concern surface structures. We will create a surface with an opening, define the thickness and material, and assign supports.
Then, we will create the static analysis settings, load case, design situation, and load combination. After that, we will apply the load on the surface.
Time Schedule:
00:00 Introduction
00:27 Geometry
03:00 Surface
04:05 Thickness
04:40 Material
05:11 Export
06:29 Opening
09:02 Supports
10:04 Static Analysis Settings
10:40 Load Case
12:54 Design Situation
14:40 Load Combination
16:34 Load Application
