Masonry Design in RFEM 6
Video
First Steps with RFEM
Description
This video shows the basic functions and options for the structural design of masonry structures.
Features:
- Stress determination using an elastic-plastic material model
- Design of masonry disc structures for compression and shear on the building model or single model
- Automatic determination of stiffness of wall-slab hinge
- Extensive material database for Austrian masonry products
- Automatic determination of material values according to Eurocode 6 (ÖN EN 1996-X)
- Option to create pushover analysis
