FAQ 005159 | Where can I adjust the standardization of a mode shape in RFEM 6 / RSTAB 9?

Question:
Where can I adjust the standardization of a mode shape in RFEM 6 / RSTAB 9?

Answer:
You can adjust the display of the mode shape standardization directly in the Results navigator. If the setting is changed, no recalculation is necessary.

Depending on the setting, the largest displacement or deformation represents the reference value 1, to which the other results are scaled.
