Standardization of Mode Shape
Can’t find the answer to your question? Contact us via phone, email, chat, or forum or send us your question directly through our online form.Submit Individual Question
Seismic Analysis in RFEM 6 is possible by using the modal analysis and the response spectrum analysis add-ons. As a matter of fact, the general concept of the earthquake analysis in RFEM 6 is based on the creation of a load case for the modal analysis and the response spectrum analysis, respectively. The standard group for these analyses are set in the Standards II tab of the model’s Base Data.
Compared to the RF-/DYNAM Pro - Natural Vibrations add-on module (RFEM 5 / RSTAB 8), the following new features have been added to the Modal Analysis add-on for RFEM 6 / RSTAB 9:
- Preset combination coefficients for various standards (EC 8, ASCE, etc.)
- Optional neglect of masses (e.g. mass of foundations)
- Methods for determining the number of mode shapes (user-defined, automatic - to reach effective modal mass factors, automatic - to reach the maximum natural frequency)
- Output of modal masses, effective modal masses, modal mass factors, and participation factors
- Tabular and graphical output of masses in mesh points
- Various scaling options for mode shapes in the result navigator
