This video shows how to apply loads to an RFEM 6 model. For this, we use the load wizard to insert member loads from an area load.
Contents:
00:00 Introduction
00:55 New member load
02:06 Member loads from area load
04:44 Display properties of loads
RFEM 6 Tutorial for Beginners | 012 Loads | Load Wizards | Member Loads from Area Loads (USA)
