SHAPE-THIN determines the effective cross-sections according to EN 1993-1-3 and EN 1993-1-5 for cold-formed sections. You can optionally check the geometric conditions for the applicability of the standard specified in EN 1993‑1‑3, Section 5.2.
The effects of local plate buckling are considered according to the method of reduced widths and the possible buckling of stiffeners (instability) is considered for stiffened sections according to EN 1993-1-3, Section 5.5.
As an option, you can perform an iterative calculation to optimize the effective cross-section.
You can display the effective cross-sections graphically.
Read more about designing cold-formed sections with SHAPE-THIN and RF-/STEEL Cold-Formed Sections in this technical article: Design of a Thin-Walled, Cold-Formed C-Section According to EN 1993-1-3.
- When calculating a connection using the FRAME‑JOINT Pro add-on module, a message appears saying that the value is out of the valid range (existing value: 108, minimum value 100, maximum value 100). What does this message mean?
- For design in FRAME‑JOINT Pro, I get Error No. 30011 "The selected nodes have different geometry [...]". How can I design my connection?
- When modeling a beam connection to a continuous column, I have the problem that the column flange fails under bending. If I add backing plates in the FRAME‑JOINT Pro add-on module, nothing changes for all design ratios. Why?
- Is it possible to use one of the RFEM/RSTAB add-on modules to design a frame corner with a docked beam, stiffeners, and any number of bolt rows?
- The design of my connection is not possible because of an incorrect geometry input. What can I do?
- I copy a design case and/or select a different or further node for the design. However, the connection geometry defined in the previous design case is not transferred. Why?
- Is it possible to avoid the extended bottom when defining an end plate, and to arrange a single-bevel groove weld? If not, what is the size of the extension?
- I would like to remodel a connection using FRAME‑JOINT Pro for comparison purposes, but have problems with bolt spacings. Are there any other spacings or have I overlooked something?
- The welds of a column head plate are very small. What is the reason?
- When calculating a connection using the FRAME‑JOINT Pro add-on module, a message appears sayng that the value is out of the valid range (existing value: 160, minimum value 200). What does this message mean?
