How can a downstand beam be retroactively modeled under an existing floor so that only vertical compressive forces are transferred?

Answer

In this case, the slab should rest on the downstand beam without any bond, see Figure 1.

Figure 01 - Ceiling with downstand beam

First, assign the "Beam member" member type to the downstand beam because the rib is not effective here due to the missing joint.

To implement the nonlinearity "Only transfer of compressive forces in Z-direction", you can use the "Line Release" function. In this case, all forces and moments must be activated, that is, released, within the "New Line Release Type" dialog box. Moreover, for u z, the nonlinearity "Fixed if v z positive" must be set, see Figure 2.

Figure 02 - Line Release Type

The line of the member within the corresponding surface must be selected as the released line, as well as the corresponding surface as the released object.

Keywords

Line release Later Downstand beam Shear coupling Composite Contact
