Answer:
No, the function for the shear force reduction that you know from RF‑CONCRETE Members is not available in RF‑CONCRETE Surfaces. RF‑CONCRETE Surfaces always performs the design in the respective FE mesh nodes or grid points.
Question
Is it also possible to reduce the shear force on a support or perform design with the shear force at a distance d to the support in RF‑CONCRETE Surfaces?
