Elastic Surface Foundation with High Spring Constant
Answer
The direct input of a spring constant of the surface foundation is possible with a maximum of 2*108 kN/m3.
However, you can edit the stiffnesses of your surface supports in your load cases or even load combinations. If you multiply the value of the spring constant by the factor 5, you can also see a stiffer support in the results.
Pay attention to the control of the stiffness modification, as explained in FAQ 4212.
