A thin-walled cantilever of QRO-profile is fully fixed on the left end, and the warping is enabled. The cantilever is subjected to a torque.
Verification Example 000050 | 3
| Number of Nodes | 3 |
| Number of Lines | 2 |
| Number of Members | 2 |
| Number of Load Cases | 1 |
| Total Weight | 0.146 tons |
| Dimensions | 13.78 x 1.31 x 1.31 feet |
| Program Version | 5.03.00 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
