Prismatic folded structure systems. Surface with conical folding. Continuous fold profile with upper edge cut by sloping plane
FPL106-a | Prismatic Folded Structure Systems. Surface with Conical Folding. Continuous Fold Profile with Upper Edge Cut by Sloping Plane
| Block parameters editable dynamically | |
| Number of Nodes | 16 |
| Number of Lines | 23 |
| Number of Members | 0 |
| Number of Surfaces | 8 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 230.894 tons |
| Dimensions (Metric) | 12,000 x 3,000 x 20,000 m |
| Dimensions (Imperial) | 39.37 x 9.84 x 65.62 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
