This model presents a detailed connection concept between LTB and HSS elements in the 2D area. It shows the intersection of the two components, focusing on the simulation of beam events. The linked image provides a schematic representation, with individual components highlighted in color and precisely dimensioned. The representation supports engineers in analyzing and optimizing connection systems. This creates a solid basis for further numerical investigations.


(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

Connection Concept of LTB to HSS

Number of Nodes 2
Number of Lines 1
Number of Members 1
Number of Load Cases 1
Total Weight 0,014 t
Dimensions (Metric) 0.402 x 4.060 x 0.402 m
Dimensions (Imperial) 1.32 x 13.32 x 1.32 feet
Program Version 5.13.00

You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
