The RF-FORM-FINDING add-on module determines equilibrium shapes of membrane and cable elements in RFEM. In this calculation process, the program searches for such a geometric position in which the surface stress/prestress of membranes and cables is in equilibrium with natural and geometric boundary conditions. his process is called form-finding (hereinafter referred to as FF). The FF calculation can be activated in RFEM globally in the "General Data" of a model, "Options" tab. After selecting the corresponding option, a new load case or a calculation process called RF-FORM FINDING is created in RFEM, and an additional FF parameter is available for defining surface stress and prestress when entering cables and membranes. By activating the FF option, the program always starts the form-finding process before the pure structural calculation of internal forces, deformation, eigenvalues, etc., and generates a corresponding prestressed model for further analysis.
Module analysis and design of a steel membrane structure for the roofing of a sports center in Fürth
Side view of the timber and steel structure of the airship with the 'umbrella' membrane (© Jan Slavík, DOX)
With the activated option "Topology on form-finding shape" in the Project Navigator - Display, the model display is optimized based on the form-finding geometry. For example, the loads are displayed in relation to the deformed system.
