Download the model of a ladder with a friction support here and open it with the structural FEA software RFEM.
This model is used in the free online basic training of the structural FEA software RFEM 6 | Introduction to FEM for Students.
Ladder with Friction Support
| Number of Nodes | 36 |
| Number of Lines | 18 |
| Number of Members | 18 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 16 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.030 tons |
| Dimensions | 4.6 x 16.09 x 1.15 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
