Hybrid Structure System | Coupling System | Combination of superposition and coupling of structure systems | Central truss connected with lateral beam with a combination of guy cable
HSS001 | Hybrid Structure System
| Block parameters editable dynamically | |
| Number of Nodes | 62 |
| Number of Lines | 91 |
| Number of Members | 75 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 608.687 tons |
| Dimensions | 72.18 x 26.25 x 118.11 feet |
