Marine ladder with parameterized geometry and metallic lateral exit aggregate.
Model created by the Dlubal Latam engineering team. The model is also available as a parameterized block on the Dlubal Latam website.
Marine Ladder with Side Exit
| Block parameters editable dynamically | |
| Number of Nodes | 188 |
| Number of Lines | 170 |
| Number of Members | 130 |
| Number of Surfaces | 10 |
| Total Weight | 0.176 tons |
| Dimensions | 8.69 x 2.11 x 21.65 feet |
| Program Version | 5.27.01 |
