This model presents an advanced analysis of a timber roof structure, integrating the display of generated loads in a printout report for a detailed assessment of transferred and variable loads. The dedicated feature allows visualization of load effects on the structure as part of FAQ 005562, enhancing understanding of load transfer. The graphical representation provides a detailed illustration of the force distribution in the structure, thus optimizing verification and diagnosis.
Model Used in
Timber roof: Accurate display of generated loads
| Number of Nodes | 279 |
| Number of Lines | 518 |
| Number of Members | 518 |
| Number of Surfaces | 2 |
| Number of Solids | 0 |
| Number of Load Cases | 2 |
| Number of Load Combinations | 7 |
| Number of Result Combinations | 0 |
| Total Weight | 4,582 t |
| Dimensions (Metric) | 13,000 x 0,240 x 16,200 m |
| Dimensions (Imperial) | 42.65 x 0.79 x 53.15 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
