This model presents a structural frame of a steel warehouse hall developed in a bachelor's thesis focusing on a comprehensive design approach. The project focuses on the structural design of the steel frame, including load analysis and the development of key elements such as the roof and wall cladding, main transverse frame, gable wall, bracing systems, and supporting elements of the internal partition wall.
Author: František Hovorka
University: Czech Technical University in Prague – Faculty of Civil Engineering
Advisor: Prof. Ing. Michal Jandera, Ph.D.
Steel Warehouse Hall Structural Frame
| Number of Nodes | 56 |
| Number of Lines | 69 |
| Number of Members | 69 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 11 |
| Number of Load Combinations | 27 |
| Number of Result Combinations | 2 |
| Total Weight | 6.957 tons |
| Dimensions (Metric) | 18.000 x 9.583 x 6.600 m |
| Dimensions (Imperial) | 59.06 x 31.44 x 21.65 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
