Invitation to Free Webinar | Stiffening Design in RFEM 6 Using Building Model

Title:
Stiffening Design in RFEM 6 Using Building Model

Date and Time:
Thu, April 25, 2024 | 2:00 PM – 3:00 PM CEST

Webinars provide you with the opportunity to gain expert knowledge and to ensure you're getting the most out of your Dlubal programs.

In this webinar, you will learn how to calculate connections with circular hollow sections in RFEM 6.

After the event, you can easily download the model(s) used in the webinar. This will allow you to independently follow the webinar step by step.

More information and registration:

Invitation to Free Webinar | Stiffening Design in RFEM 6 Using Building Model
