Question

I cannot open the dialog box for entering the soil profile in FOUNDATION Pro anymore. Why?

Answer

The dialog box for defining the soil profile is deactivated when deactivating the dependent designs in the detail settings.

It is not required to enter a soil profile for the following design types:

  • Ground failure resistance according to EN 1997-1, Annex D
  • Sliding design
  • Settlement calculation

As soon as you activate one of the options mentioned above, the dialog box for entering the soil profile will also be available again.
