Support Types and Supports
Video
First Steps with RFEM
Description
This video is all about supports. Which types are available, how they are displayed, what they look like, and much more.
In simple terms, supports are the connections between a structure and a fixed point. Depending on the support type, they prevent certain displacements or rotations of the structure.
We show you the most common types in structural engineering, which movements they allow (the so-called degrees of freedom) and the respective support forces that can occur.
Have fun!
Keywords
Dlubal Infotainment Support Roller support Pinned support Fixed support Restrained support Nodal support E-learning Entertainment Construction industry Civil engineering Civil engineer Studies Structural engineering Structural engineer Civil engineering studies Structural analysis
