The most important formulas of a civil engineer Part 2
Video
First Steps with RFEM
Description
In the second part we extend our selection of the most important formulas for civil engineers to provide you with even more useful formulas and tools for your everyday life as civil engineers and students.
This time, we go into detail and look at more complex cross-sections and quick estimations.
Find the first part in our channel and on the Dlubal website.
Have fun!
00:00 Introduction
00:20 Design of Concrete Compression Elements Without Reinforcement
01:12 Estimating Amount of Reinforcing Steel in a Beam
03:02 Calculation of Centroid of Complex Cross-Sections
03:58 Second Moment of Area of Welded I-Sections
04:38 Elastic Design of Steel Beam
Keywords
Structural analysis - basics Formula Cross-section properties Second moment of area Moment partial safety factor Civil engineering Civil engineering studies Structural analysis Structural engineering
