This short video presents the most important new features of the past month.
In October 2022, the following functions have been implemented in RFEM 6 and RSTAB 9, among other things:
00:00 Shear joint for ribs
00:21 Separated imperfections according to Eurocode 2 and Eurocode 3
00:38 Member type "Surface Model"
01:05 Reduction of stiffness for "layers"
Product Feature
Product Feature
Product Feature
It is possible to save different model versions within a model by using the Save as Version function. In the Base Data of the model, the different model versions can be displayed in the History tab.
Using the "Beam Panel" thickness type, you can model timber panel elements in 3D space. You just specify the surface geometry and the timber panel elements are generated using an internal member-surface construct, including the simulation of the connection flexibility.
You have the option to perform the fire resistance design of surfaces using the reduced cross-section method. The reduction is applied over the surface thickness. It is possible to perform the design checks for all timber materials allowed for the design.
For cross-laminated timber, depending on the type of adhesive, you can select whether it is possible for individual carbonized layer parts to fall off, and whether you can expect increased charring in certain layer areas.
