FAQ 005569 | How can I display the sag of a member directly in the model?

Question:
How can I display the sag of a member directly in the model?

Answer:
To display the member sag, proceed as follows:

1. Create a linear dimension on the member. This can be done by sections or over the entire member length.
2. Display a global displacement as the result.
3. Activate the "Results in Section" option under "Dimensions" in the Navigator – Results.

You can now read out the member sag from the dimensioning. This corresponds to the greatest magnitude of an imaginary line between the deflected start and end of the considered member section.

► Image | FAQ 005569 | Dimension with Member Sag | Illustration 1 https://www.dlubal.com/en/img/051463

Step 1: Creating Linear Dimension

► Image | FAQ 005569 | Dimension with Member Sag | Step 1 https://www.dlubal.com/en/img/051441

Step 2: Displaying Global Displacement

► Image | FAQ 005569 | Dimension with Member Sag | Step 2 https://www.dlubal.com/en/img/051442

Step 3: Activating Results on Members

► Image | FAQ 005569 | Dimension with Member Sag | Step 3 https://www.dlubal.com/en/img/051444
