How can I import an IGES or STEP file into RFEM?

Answer

For the import of the *.igs or *.stp (STEP) files, the RX‑LINK add-on module is required (see Figure 01). The export is currently not possible.

Furthermore, it is possible to import a model with the CAD/BIM option. After selecting the file to be imported, it can be activated in the Options tab of the "New Model - General Data" dialog box (see Figure 02). This option allows you to additionally convert the geometric elements directly into members, surfaces, or solids after the import (see Figure 03).

Keywords

CAD BIM STEP IGES Import Export
