Four columns are fixed at the bottom and connected by the rigid block at the top. Block is loaded by pressure and modeled by an elastic material with a high modulus of elasticity. Outer columns are modeled by linear elastic material and inner columns by a stress-strain diagram with the decaying dependence. Assuming only small deformations theory and neglecting structure's self-weight, determine its maximum deflection.
Verification Example 000014 | 1
| Number of Nodes | 28 |
| Number of Lines | 49 |
| Number of Surfaces | 24 |
| Number of Solids | 3 |
| Number of Load Cases | 1 |
| Dimensions | 1.15 x 0.33 x 3.61 feet |
| Program Version | 5.05.11 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
