Wooden gallery with pneumatic cushion
Model to Download
Wooden gallery with pneumatic cushion as light opening
Model Used in
- Views 295x
- Downloads 61x
- Updated 24 November 2020
- Size 80,72 MB
- Number of nodes 70
- Number of Lines 100
- Number of Members 100
- Number of Surfaces 14
- Number of solids 1
- Number of load cases 8
- Number of load combinations 23
- Number of Result Combinations 3
- Total weight 16.844 t
- Dimensions 10,322 x 10,322 x 6,180 m
- Program Version 5.24.01.156530
