Hybrid Structure System | Superposition System | Superposition of section-active and form-active structure systems | Cable supported hinged frames | Cable supported two-hinged polygonal frame
HSS006-b | Hybrid Structure System
| Block parameters editable dynamically | |
| Number of Nodes | 79 |
| Number of Lines | 89 |
| Number of Members | 70 |
| Number of Surfaces | 6 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 409.989 tons |
| Dimensions | 59.06 x 27.89 x 118.11 feet |
