Concrete single-flight staircase supported by a central spine beam with top landing. The spine beam runs underneath the treads of the staircase and is anchored to the surrounding structure, providing stability and support.


(0)
0 out of 5 stars
5 star 0
4 star 0
3 star 0
2 star 0
1 star 0

STC032 | Single-Flight Staircase with Top Landing

Block parameters editable dynamically
Number of Nodes 52
Number of Lines 52
Number of Members 0
Number of Surfaces 9
Number of Solids 0
Number of Load Cases 1
Number of Load Combinations 0
Number of Result Combinations 0
Total Weight 1.869 tons
Dimensions 3.94 x 4.46 x 10.25 feet
