Braced concrete retaining wall in sandy terrain. Multiple soil levels.
A model created by the Dlubal Latam engineering team. The model is also available as a parameterized block on the Dlubal Latam website.
Braced Retaining Wall
| Block parameters editable dynamically | |
| Number of Nodes | 70 |
| Number of Lines | 124 |
| Number of Members | 1 |
| Number of Surfaces | 64 |
| Number of Solids | 9 |
| Number of Load Cases | 1 |
| Dimensions | 131.23 x 104.99 x 45.93 feet |
| Program Version | 5.19.01 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
