Design of an open-air stage roof structure used in Graduation Thesis 000480. The model depicts an open-air stage roof with a lightweight, free-form structure, creating a visually striking wave-like canopy that blends aesthetics and functionality. It utilizes a triangular mesh framework, a space frame structure design.
Open-Air Stage Roof Structure
| Number of Nodes | 145 |
| Number of Lines | 576 |
| Number of Members | 496 |
| Number of Surfaces | 128 |
| Number of Solids | 0 |
| Number of Load Cases | 11 |
| Number of Load Combinations | 147 |
| Number of Result Combinations | 1 |
| Total Weight | 84.580 t |
| Dimensions | 45.000 x 22.414 x 32.615 m |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
