Finite Element Model of Cable Clamp in RFEM 6 | © Jiangsu Jingong Space Structure Co., Ltd.
Model of Cable Clamp in RFEM 6
No Download Possible
Customer Project / for View Only
| Number of Nodes | 38 |
| Number of Lines | 77 |
| Number of Members | 0 |
| Number of Surfaces | 46 |
| Number of Solids | 6 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 0 |
| Total Weight | 0.004 tons |
| Dimensions | 0.59 x 0.46 x 0.47 feet |
