The model "Stair Tower" was authored by Patrik Andel from the Department of Steel and Timber Structures at CTU in Prague. The work is part of the Dlubal Talent CTU competition. The structure consists of steel stair flights and an upper intermediate landing, which are modeled as separate welded assemblies. The railing is included for load transfer and stiffness effects, assessed manually. The joints of the railing posts are free only around the axis perpendicular to the railing plane. Nonlinear supports were determined for the selected limit state.
Staircase Tower
| Number of Nodes | 1254 |
| Number of Lines | 703 |
| Number of Members | 696 |
| Number of Surfaces | 5 |
| Number of Solids | 0 |
| Number of Load Cases | 8 |
| Number of Load Combinations | 34 |
| Number of Result Combinations | 0 |
| Total Weight | 5,067 t |
| Dimensions (Metric) | 2 055,764 x 10,736 x 3 404,915 m |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
