The model was calculated according to the large deformation analysis.
Pulley with Cables
The pulley was generated and analyzed in 15 minutes during a presentation at CeBIT 2002 in response to a customer's request.
Project Specifications
Pulley with Cables
Model data
Number of Nodes
75
Number of Members
80
Number of Load Cases
1
Total Weight
4.678 tons
Dimensions
3.41 x 5.18 x 11.91 feet
Program Version
6.02.09
