Steel Hall with 80-ton Double-Girder Overhead Crane

Academic project involving the structural design of a 30 × 15 m steel industrial building with an 80-ton overhead crane, modeled and analyzed in RFEM 6. The attached report covers loading, structural stability, member checks, and functionality.

Author	Raúl Vásquez
University	University of Zaragoza, Spain

3D model of an industrial metal building with a gable roof, trapezoidal facade panels, and steel frames for a master's thesis project.

3D Model of Industrial Hall with Steel Structure and Gable Roof

The facility, located in Teruel, Spain, is designed for the manufacturing and handling of steel products. The design includes an 80-ton double-girder overhead crane inside the facility, which is required for the production process and the movement of heavy loads.

The industrial building for Group 1 is constructed using a metal structure consisting of rigid transverse frames, trusses on the central axes, beams on the gable axes, and rolled roof purlins. The 10% slope ensures proper water drainage and the correct installation of the sandwich panels.
