RFEM | Structural dynamics and earthquake design according to EC 8
Information about online training
Why An Online Training?
Online group training sessions provide the opportunity to gain expert knowledge and to ensure you’re getting the most out of your Dlubal programs.
Date | Time
Event Language
EnglishContent
Online basic training on earthquake design according to Eurocode 8 using the FEM static program RFEMIn this training you will learn the basics of structural dynamics and the most important verification methods for earthquake design. Using a practical example, the multi-modal response spectrum method and its implementation in RFEM and the associated modules of the RF-DYNAM Pro series is explained. Open questions can be discussed.
Price
195.00 EUR net, excluding VATTime Schedule
| - | Standards |
| - | Overview of possible design methods |
| - | Multi-Modal response spectrum analysis |
| - | Practical example 1: Response spectrum analysis |
| - | Dynamic actions on structures |
| - | Practical example 2: Machine induced vibrations |
Additional information
A reliable internet connection is required to participate. Basic knowledge in the use of RSTAB or RFEM is also required. The online training is carried out using RFEM with the associated add-on modules.During the training, each participant can ask questions via chat at any time.
Each participant receives after the event:
- Training certificate
- Training presentation for download
- Used models for download
- Video recording of the training
In order to take part in the online training, the participant will receive the login information in time.
Speakers
Dipl.-Ing. (FH) Stefan Frenzel
Product Engineering & Customer Support
Mr. Frenzel is responsible for the development of products for dynamic analysis. He also provides technical support for customers of Dlubal Software.
Stefan Hoffmann, M.Sc.
Product Engineering & Customer Support
Mr. Hoffmann is responsible for the development of the products for dynamic analysis, membrane structures, and RWIND. Furthermore, he provides technical support for our customers.
