Plate and Shell Modeling in RFEM - Part 1
Free Online Seminar
Everything I Expected and More
"RFEM is everything I expected and more. I’m having a blast learning the software and the webinars are fantastic."
Nicholas J. Greven P.Eng.
23 July 2019
Date
Event Language
EnglishContent
- Introduction to RFEM and RF-LAMINATE add-on module
- Analysis of CLT structure
- Design of CLT structure per CSA O86:14
- Tips for optimal modeling
Time Schedule
| 00:00 | Introduction |
| 01:49 | Review of initial structure geometry and loading in RFEM |
| 08:45 | CLT input data in RF-LAMINATE |
| 29:18 | Application of "line releases" and "line hinges" |
| 42:05 | Analysis and design of CLT panels according to CSA O86:14 |
| 45:55 | Addressing FEA singularities with "FE mesh refinements" and "average regions" |
| 54:58 | Review of additional results including members and joints |
| 58:32 | Conclusion |
