ACI 318-14 Concrete Column and Beam Design in RFEM
Free Online Seminar
- Modeling, loading, and analysis of a concrete structure in RFEM
- ACI 318-14 strength & serviceability design with the add‑on modules RF‑CONCRETE Members and RF‑CONCRETE Columns
- Longitudinal, shear, and torsional reinforcement design
|01:20||Concept of RFEM and RF‑CONCRETE Members/Columns add-on modules|
|02:35||Structural analysis and design in RFEM|
|10:15||RF‑CONCRETE Members - ACI design of reinforced concrete members and beams|
|44:10||Slenderness and curvature effects - compression members|
|48:05||RF‑CONCRETE Columns - ACI design of reinforced concrete columns|
Amy Heilig, PE
CEO - USA Office
Sales & Technical Support Engineer
Amy Heilig is the CEO of the USA office located in Philadelphia, PA. In addition, she provides sales and technical support and continues to aid in the development of Dlubal Software programs for the North American market.
