ACI 318-14 Concrete Slab Design in RFEM
Free Online Seminar
- Modeling, loading, and analysis of reinforced concrete slabs in RFEM
- ACI 318-14 strength and serviceability design with the add‑on module RF‑CONCRETE Surfaces
- Explore both automated and user-defined reinforcement areas
- Deflection analysis considering creep/shrinkage with the add‑on module RF‑CONCRETE Deflect
|02:20||Concept of the RF‑CONCRETE add‑on modules|
|04:55||Example – Introduction, model and loads|
|19:40||Example – Case 1: Strength limit state design|
|34:00||Example – Case 2: Strength & Service limit state design with basic reinforcement|
|45:08||Example – Case 3: Strength & Service limit state design with user‑defined reinforcement areas|
|56:32||Example – Case 4: Deflection analysis with RF‑CONCRETE Deflect|
|1:06:30||Example – Export of reinforcement|
