A thin-walled spherical vessel is loaded by inner pressure. While neglecting self‑weight, determine the von Mises stressand the radial deflection of the vessel.
Verification Example 000084 | 2
| Number of Nodes | 7 |
| Number of Lines | 4 |
| Number of Surfaces | 1 |
| Number of Load Cases | 1 |
| Total Weight | 0.015 tons |
| Dimensions | 2.33 x 2.33 x 2.33 feet |
| Program Version | 5.11.02 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
