The model is created using the Steel Joints add-on in RFEM 6 and analyzed for joint buckling.
Steel Joint with Haunch for Connecting Beam to Column
| Number of Nodes | 895 |
| Number of Lines | 740 |
| Number of Members | 408 |
| Number of Surfaces | 64 |
| Number of Solids | 0 |
| Number of Load Cases | 32 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 0.212 tons |
| Dimensions | 4.46 x 3.86 x 0.98 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
