A single-span steel beam is a simple, but effective beam that carries loads over a single span. It is often used in building structures to provide structural stability because of its strength and durability.
Single-Span Steel Beam
| Number of Nodes | 11 |
| Number of Lines | 10 |
| Number of Members | 10 |
| Number of Surfaces | 0 |
| Number of Solids | 0 |
| Number of Load Cases | 3 |
| Number of Load Combinations | 1 |
| Number of Result Combinations | 1 |
| Total Weight | 0.571 tons |
| Dimensions | 32.81 x 0 x 0 feet |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
