Question:
I have a model with relatively short members as couplings. The display of internal forces is confusing due to the short members. Is there any way to display the internal forces so that they are legible?
Answer:
In this case, the "Without Diagram" display option for members is suitable:
"Display" navigator → "Results" → "Members" → "Without Diagram"; see Image 01.
