Parameterization of the geometry of a square section metal column, attached to the base plate, linked to a foundation block through four anchor bolts.
Model created by the Dlubal Latam engineering team. The model is also available as a parameterized block on the Dlubal Latam website.
Column – Base Connection
| Block parameters editable dynamically | |
| Number of Nodes | 98 |
| Number of Lines | 85 |
| Number of Members | 5 |
| Number of Surfaces | 42 |
| Number of Solids | 3 |
| Total Weight | 0.526 tons |
| Dimensions | 1.97 x 1.97 x 3.82 feet |
| Program Version | 5.28.01 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
