Online Manual RFEM | Surfaces
Complete parameterization block of the connection geometry, control of the connection angle, contact solid, connection plate, hole size, and connection plate thicknesses.
A model created by the Dlubal Latam engineering team. The model is also available as a parameterized block on the Dlubal Latam website.
Beam and Column Connection
| Block parameters editable dynamically | |
| Number of Nodes | 100 |
| Number of Lines | 85 |
| Number of Members | 10 |
| Number of Surfaces | 42 |
| Number of Solids | 1 |
| Number of Load Cases | 1 |
| Total Weight | 0.087 tons |
| Dimensions | 0.85 x 2.87 x 2.49 feet |
| Program Version | 5.11.02 |
You can download this structural model to use it for training purposes or for your projects. However, we do not assume any guarantee or liability for the accuracy or completeness of the model.
